RM Stelflow 250L High Gain Indirect Cylinder - TRSMVH-0250LFC
Shipping time: 2–7 days
Please call us for precise delivery dates.
Description
The RM Stelflow 250L High Gain Indirect Cylinder (TRSMVH-0250LFC) is a high-performance indirect hot water cylinder engineered for reliable, efficient domestic and light-commercial hot water systems. Designed to work with external boilers or heat sources via its large stainless-steel coil, it delivers stable, high-capacity hot water while minimising heat loss. Suited to homes, apartments, and commercial installations, it offers durable construction, strong thermal insulation and long-term reliability for installers and end users.
Key Features
- 236 L actual hot water capacity — large usable volume for family or multi-point use
- High-gain indirect design compatible with external boilers and central heating systems
- Single 316L stainless-steel coil (26.7 kW rating, 2.5 m² surface) for efficient heat transfer
- Durable LDX 2101 stainless-steel cylinder for corrosion resistance and longevity
- Coated mild steel outer casing with dense PU foam (50 mm) insulation to reduce standby heat loss
- Low heat loss (1.752 kWh/24h) for improved energy efficiency and lower running costs
- Safety rated to 90 °C and tested to BS EN 12897:2016 for performance and reliability
- High-pressure capability: max mains 10 bar, operating pressure 7 bar (coil max primary 6 bar)
- Single immersion port (immersion spec 3) and one heat exchanger for simplified installation
- 25-year warranty for long-term assurance
Ideal Use Cases
- Residential family homes needing a large domestic hot water store
- Multi-bathroom properties and apartments with multiple simultaneous hot water draws
- Small to medium commercial buildings or staff facilities requiring reliable hot water supply
- Integration with boilers, heat pumps, or central heating systems as an indirect cylinder
- Renovation projects replacing older cylinders where improved insulation and capacity are required
- Kitchens, bathrooms and utility areas demanding consistent hot water performance
Product Specifications
| Specification | Value |
|---|---|
| Product model | RM Stelflow 250L High Gain Indirect Cylinder (TRSMVH-0250LFC) |
| Actual capacity (Ltr) | 236 |
| Unit weight empty (kg) | 57.6 |
| Unit weight full (kg) | 293.4 |
| No immersions | 1 |
| Immersion spec | 3 |
| No heat exchangers | 1 |
| Coil 1 rating (kW) | 26.7 |
| Coil 1 surface area (m²) | 2.5 |
| Coil 1 max prim pressure (Bar) | 6 |
| Coil 1 resistance (Bar) | 0.07 |
| Max mains water pressure (Bar) | 10 |
| Operating pressure (Bar) | 7 |
| Operating temp (°C) | 60 |
| Safety valve temp (°C) | 90 |
| Thermal insulation | Dense PU foam |
| Foam thickness (mm) | 50 |
| Cylinder material | LDX 2101 |
| Outer casing | Coated mild steel |
| Coil material | 316L stainless steel |
| Heat loss (kWh/24h) | 1.752 |
| Tested to standard | BS EN 12897:2016 |
| Warranty terms (Year) | 25Y |
