Joule Cyclone Platinum 250L Direct Smart Short C Unvented Cylinder – TCEMVD-0250NFC is a high-capacity direct unvented hot water cylinder designed to provide reliable mains-pressure hot water for larger residential properties and light-commercial applications. With a compact short-form design, it is suited to installations where available vertical space is limited while a large hot water storage capacity is still required.
Manufactured with an LDX 2101 stainless steel cylinder, coated mild steel outer casing and dense PU foam insulation, the Cyclone Platinum 250L provides a durable construction with effective heat retention. Two 3kW @ 230V immersion heaters provide electric heating capability, while the cylinder supports a maximum mains water pressure of 10 bar and an operating pressure of 7 bar. The cylinder is tested to BS EN 12897:2016 and is backed by a 25-year warranty.
250L Capacity
Direct Unvented
Smart Short C
25-Year Warranty
Immersion Heaters
2 × 3kW
Applications & suitability
Larger homes
The 250-litre capacity is designed for larger residential properties with higher hot water requirements.
Light-commercial sites
Suitable for smaller commercial properties, guest houses and staff facilities requiring high-capacity hot water storage.
Space-limited installations
The short-form design is suited to renovations and retrofits where vertical installation space is restricted.
New-build projects
Designed for projects specifying a direct unvented cylinder capable of delivering mains-pressure hot water.
Key specifications
| Model |
TCEMVD-0250NFC |
| Brand |
CYCLONE |
| Capacity |
250 L |
| Actual Capacity |
250 L |
| Product Group Code |
DIRECT |
| Item Category Code |
Stainless |
| ERP Type |
DirectUnvented |
| Cylinder Material |
LDX 2101 Stainless Steel |
| Outer Casing |
Coated Mild Steel |
| Thermal Insulation |
Dense PU Foam |
| Foam Thickness |
0 mm |
| No. of Immersions |
2 |
| Immersion Specification |
3 kW @ 230 V |
| Max Mains Water Pressure |
10 bar |
| Operating Pressure (T&P) |
7 bar |
| Safety Temperature |
90 °C |
| Unit Weight Empty |
43 kg |
| Unit Weight Full |
293 kg |
| Heat Loss |
2.09 kWh/24h |
| Tested to Standard |
BS EN 12897:2016 |
| Warranty Terms |
25 years |
Installation & compatibility
Direct unvented configuration: The TCEMVD-0250NFC is designed for compatible mains-pressure hot water systems. Its short-form design provides a compact alternative for installations where available vertical space is limited, while the 250-litre capacity provides substantial hot water storage.
Design & performance benefits
250L high-capacity storage
Provides 250 litres of actual hot water storage for properties with higher hot water demand.
Short-form design
The Smart Short C format is designed for applications where installation space is restricted but high capacity is required.
LDX 2101 stainless steel
The cylinder uses LDX 2101 stainless steel construction, with a coated mild steel outer casing.
Dense PU insulation
Dense PU foam insulation contributes to heat retention, with a specified heat loss of 2.09 kWh/24h.
Additional installation features
Two immersion heaters
The cylinder features two immersion heaters with a specification of 3kW @ 230V.
High-pressure capability
Supports a maximum mains water pressure of 10 bar and an operating pressure of 7 bar.
BS EN 12897:2016
The cylinder is tested to BS EN 12897:2016 and supplied with a 25-year warranty.
Ideal for
Larger residential properties
Suitable for larger homes with multiple bathrooms or high hot water usage.
Light-commercial applications
Designed for smaller commercial properties, guest houses and staff facilities.
Retrofit & renovation
The short design is useful where vertical space is restricted but a 250L cylinder is required.
High-capacity hot water systems
A suitable option for installations requiring mains-pressure hot water, substantial storage and long-term durability.
The Joule Cyclone Platinum 250L Direct Smart Short C Unvented Cylinder combines 250-litre hot water storage with a compact short-form design, LDX 2101 stainless steel construction and two 3kW immersion heaters. With a 10-bar maximum mains pressure, 7-bar operating pressure, 2.09 kWh/24h heat loss and 25-year warranty, the TCEMVD-0250NFC is designed for high-capacity direct unvented hot water installations where space and performance are important considerations.
