Joule Cyclone Platinum 200L Twin Coil Solar Slimline Cylinder C - TCEMVS-0200SFC
Shipping time: 2–7 days
Please call us for precise delivery dates.
Description
The Joule Cyclone Platinum 200L Twin Coil Solar Slimline Cylinder (TCEMVS-0200SFC) is a slim-profile, stainless‑steel indirect unvented cylinder engineered for solar‑assisted hot water systems. With a usable capacity of 192 L and twin 316L stainless coils, it efficiently combines solar thermal with a conventional heat source to deliver reliable domestic hot water up to 60°C. Compact, well‑insulated and corrosion‑resistant, it’s ideal where space is limited but high performance and low standby loss are required.
Key Features
- Capacity: 200 L (actual 192 L) — suited to medium-to-large households
- Twin coils: two 316L stainless steel heat exchangers (19 kW + 15 kW) for dedicated solar and primary source inputs
- Cylinder material: LDX 2101 stainless steel for long‑term corrosion resistance
- Slimline design: compact footprint for tight plant rooms or cupboards
- Thermal insulation: dense PU foam to minimise standby heat loss (heat loss 2.02 kWh/24h)
- Single immersion provision (3 kW @ 230 V) for electric boost/backup
- Outer casing: coated mild steel for a durable, serviceable finish
- Pressure ratings: max mains water pressure 10 bar; operating pressure 7 bar
- Safety & standards: tested to BS EN 12897:2016; safety valve set to 90°C
- Installation weights: empty 50 kg; full 242 kg — for siting and handling planning
Ideal Use Cases
- Homes using solar thermal with a boiler or heat pump backup
- Properties with limited plant‑room depth needing a slim cylinder profile
- Medium households with multiple hot‑water outlets (showers/baths/kitchen)
- Renovation or new‑build projects integrating renewable and conventional heat sources
Product Specifications
| Specification | Value |
|---|---|
| Model | TCEMVS-0200SFC |
| Brand | CYCLONE |
| Capacity | 200 L (actual 192 L) |
| Item Category Code | IndirectUnvented |
| Product Group Code | CYCLONE |
| Product Type | Stainless Solar Twin‑Coil Indirect Cylinder |
| Cylinder material | LDX 2101 stainless steel |
| Outer casing | Coated mild steel |
| Thermal insulation | Dense PU foam |
| Foam thickness | 0 |
| No. of immersions | 1 |
| Immersion spec | 3 kW @ 230 V |
| No. heat exchangers | 2 |
| Coil material | 316L stainless steel |
| Coil 1 rating | 19 kW |
| Coil 1 surface area | 0.56 m² |
| Coil 1 max primary pressure | 3.5 bar |
| Coil 1 resistance | 0.05 bar |
| Coil 2 rating | 15 kW |
| Coil 2 surface area | 0.56 m² |
| Coil 2 max primary pressure | 3.5 bar |
| Max mains water pressure | 10 bar |
| Operating pressure | 7 bar |
| Operating temperature | 60 °C |
| Safety valve temperature | 90 °C |
| Tested to standard | BS EN 12897:2016 |
| Heat loss | 2.02 (kWh/24h) |
| Unit weight empty | 50 kg |
| Unit weight full | 242 kg |
| Warranty terms | 1 year |
