Joule Cyclone Platinum 125L Indirect Horizontal Standard B Unvented Cylinder - TCIMHI-0125LFB
Shipping time: 2–7 days
Please call us for precise delivery dates.
Description
The Joule Cyclone Platinum 125L Indirect Horizontal Standard B Unvented Cylinder (TCIMHI-0125LFB) is a compact, high-quality horizontal indirect unvented cylinder designed to provide reliable hot water when heated via a primary boiler, heat pump, or solar thermal system. Manufactured from LDX 2101 stainless steel with dense PU foam insulation and a coated mild-steel outer casing, it delivers efficient heat retention and corrosion resistance in confined plant rooms or under-cupboard installations. Suited to smaller homes, apartments or utility spaces, it offers fast heat exchange and dependable performance for indirect heating systems.
Key Features
- Actual capacity: 124 L — compact footprint for space-restricted installations
- Indirect unvented design for use with boilers, heat pumps or solar thermal systems
- Horizontal orientation for under-bench or plant-room placement
- Cylinder material: LDX 2101 stainless steel for durability and corrosion resistance
- Outer casing: coated mild steel for a neat, protective finish
- Dense PU foam insulation to minimise heat loss (Heat loss: 1.25 kWh/24h)
- Single 316L stainless-steel coil (Coil 1 rating: 20 kW; surface area: 0.57 m²) for efficient heat transfer
- One immersion heater provision (3 kW @ 230 V) for auxiliary heating
- Coil maximum primary pressure: 3.5 bar; coil resistance: 45 bar
- Maximum mains water pressure: 10 bar; operating pressure: 7 bar
- Safety valve temperature: 90 °C
- Short 1-year warranty (check installation requirements)
Ideal Use Cases
- Small residential homes, flats or apartments needing a space-saving hot-water cylinder
- Installations heated via central boiler, heat pump or solar thermal loop
- Under-bench or plant-room installations where a horizontal cylinder fits better than vertical units
- Renovation or retrofit projects with limited vertical clearance
- Systems requiring a single robust stainless-steel heat exchanger for rapid heat delivery
Product Specifications
| Specification | Value |
|---|---|
| Model | TCIMHI-0125LFB |
| Brand | CYCLONE |
| Capacity (L) | 124 |
| Actual capacity (Ltr) | 124 |
| Product Group Code | CYCLONE |
| Item Category Code | Stainless |
| ERP Type | IndirectUnvented |
| Cylinder material | LDX 2101 (stainless steel) |
| Outer casing | Coated mild steel |
| Thermal insulation | Dense PU foam |
| Foam thickness (mm) | 0 |
| No immersions | 1 |
| Immersion spec | 3 kW @ 230 V |
| Coil material | 316L stainless steel |
| No heat exchangers | 1 |
| Coil 1 rating (kW) | 20 |
| Coil 1 surface area (m²) | 0.57 |
| Coil 1 max primary pressure (bar) | 3.5 |
| Coil 1 resistance (Bar) | 45 |
| Max mains water pressure (bar) | 10 |
| Operating pressure (bar) | 7 |
| Operating temp (°C) | 0 |
| Safety valve temp (°C) | 90 |
| Unit weight empty (kg) | 30 |
| Unit weight full (kg) | 155 |
| Heat loss (kWh/24h) | 1.25 |
| Warranty terms (years) | 1Y |
