Joule Cyclone Platinum 100L Direct Slimline B Unvented Cylinder - TCEMVD-0100SFD
Shipping time: 2–7 days
Please call us for precise delivery dates.
Description
The Joule Cyclone Platinum 100L Direct Slimline B Unvented Cylinder (TCEMVD-0100SFD) is a compact, high-performance direct unvented hot water cylinder designed for installations where space is limited but mains-pressure hot water is required. With twin immersion capability and stainless-steel construction, it provides reliable, rapid heating and consistent high-pressure supply to multiple outlets. Ideal for small homes, flats and retrofits, it combines slimline design, effective insulation and long-term warranty for dependable everyday use.
Key Features
- 100 L actual usable capacity — compact yet practical for small households
- Direct unvented design delivering mains-pressure hot water to showers and taps
- Two immersion ports compatible with 3 kW, 230 V elements for fast recovery and redundancy
- LDX 2101 stainless-steel cylinder for excellent corrosion resistance and durability
- Dense PU foam insulation with coated mild steel outer casing to reduce standby heat loss
- Slimline footprint ideal for cupboards, plantrooms and tight utility spaces
- Low heat loss (1.34 kWh/24h) for improved energy efficiency
- High-pressure capability: max mains 10 bar, operating pressure 7 bar
- Safety temperature rated to 90 °C and tested to BS EN 12897:2016
- 25-year warranty for long-term peace of mind
Ideal Use Cases
- Small homes, flats and one- to two-person households needing mains-pressure hot water
- En-suites, bathrooms and kitchens with limited plantroom or cupboard space
- Retrofit projects replacing gravity-fed cylinders with a compact unvented solution
- Properties without a cold-water storage tank where high-pressure outlets are required
- Utility rooms and apartments prioritising low maintenance and stainless-steel construction
Product Specifications
| Specification | Value |
|---|---|
| Product model | Joule Cyclone Platinum 100L Direct Slimline B Unvented Cylinder (TCEMVD-0100SFD) |
| Capacity (listed) | 100 L |
| Actual capacity (Ltr) | 100 |
| Unit weight empty (kg) | 32 |
| Unit weight full (kg) | 125 |
| No immersions | 2 |
| Immersion spec (kW @ 230V) | 3 kW @ 230 V |
| Thermal insulation | Dense PU foam |
| Foam thickness (mm) | 0 |
| Cylinder material | LDX 2101 |
| Outer casing | Coated mild steel |
| Max mains water pressure (Bar) | 10 |
| Operating pressure (Bar) | 7 |
| Safety temp (°C) | 90 |
| Heat loss (kWh/24h) | 1.34 |
| Tested to standard | BS EN 12897:2016 |
| Warranty terms (Year) | 25Y |
