Joule Cyclone 150 Litre Direct Standard Unvented Cylinder (TCEMVD-0150LFD)
Free Local Shipping
Free Local Shipping on orders over £100. Standard delivery to most UK postcodes within 1-2 working days. Express options available at checkout for more information, see here
Contact Us
Give Us A Call +44 118 958 8882 Our team is here to help. We will provide expert advice on specifications, compatibility, and delivery
30-day Easy Return
30 days Easy Return — no questions asked. If you're not completely satisfied, send it back within 30 days for a full refund.
Description
The Joule Cyclone 150 Litre Direct Standard Unvented Cylinder (TCEMVD-0150LFD) is a compact, high-performance direct unvented hot water cylinder designed to provide reliable mains-pressure hot water from a slim stainless-steel vessel. With a 150 litre actual capacity, it is well suited to small to medium homes, flats and installations where space is limited.
Using electric immersion heating, the Joule Cyclone Direct Standard cylinder is designed to provide consistent hot water to showers, taps and multiple outlets. Its LDX 2101 stainless-steel cylinder, dense PU foam insulation and coated mild steel outer casing provide a durable construction while helping to reduce heat loss. The cylinder is rated for up to 10 bar maximum mains water pressure and has a 25-year warranty for long-term peace of mind.
Key Highlights
Ideal Use Cases
- Small to medium homes and flats requiring reliable mains-pressure hot water.
- Bathrooms and kitchens requiring strong showers and multiple simultaneous hot water draws.
- Retrofit projects replacing gravity-fed systems with a compact unvented hot water cylinder.
- Properties without cold-water storage tanks or with limited plantroom space.
- Utility rooms and apartments prioritising low-maintenance stainless-steel construction.
Key Specifications
| Product Model | Joule Cyclone 150 Litre Direct Standard Unvented Cylinder (TCEMVD-0150LFD) |
| Brand | CYCLONE |
| ERP Type | DirectUnvented |
| Item Category Code | Stainless |
| Product Group Code | CYCLONE |
| Model Type | DIRECT |
| Actual Capacity | 150 L |
| Unit Weight Empty | 30 kg |
| Unit Weight Full | 180 kg |
| Number of Immersions | 2 |
| Immersion Specification | 3 kW @ 230 V |
| Thermal Insulation | Dense PU foam |
| Foam Thickness | 0 mm |
| Cylinder Material | LDX 2101 |
| Outer Casing | Coated mild steel |
| Maximum Mains Water Pressure | 10 Bar |
| Operating Pressure | 7 Bar |
| Safety Temperature | 90°C |
| Heat Loss | 1.32 kWh/24h |
| Tested To | BS EN 12897:2016 |
| Warranty | 25 Years |
Direct Unvented Hot Water Storage
The Joule Cyclone 150L direct unvented cylinder is designed to provide hot water directly from the mains supply. Its unvented configuration makes it suitable for installations requiring mains-pressure hot water without relying on a traditional gravity-fed arrangement.
With an actual 150 litre capacity, the cylinder is suited to small and medium-sized domestic installations where dependable hot water storage and efficient use of available space are important.
LDX 2101 Stainless-Steel Construction
The cylinder is manufactured using LDX 2101 stainless steel, providing a durable vessel construction for domestic hot water storage. The stainless-steel design is combined with a coated mild steel outer casing for a robust overall cylinder assembly.
Dual Immersion Heating
The Joule Cyclone TCEMVD-0150LFD features two immersion ports, with each immersion specified at 3 kW @ 230 V. This direct electric heating configuration provides a dedicated method of heating the stored domestic hot water.
Insulation and Heat Loss
The cylinder uses dense PU foam thermal insulation to help reduce heat loss from the stored water. The specified heat loss is 1.32 kWh/24h, supporting efficient hot water storage and helping minimise standby energy losses.
Pressure and Temperature Performance
The cylinder is specified for a maximum mains water pressure of 10 bar and an operating pressure of 7 bar. It has a stated safety temperature of 90°C and is tested to BS EN 12897:2016.
Ideal For
- Small to medium domestic properties.
- Flats and apartments with limited installation space.
- Homes requiring mains-pressure hot water.
- Retrofit installations replacing gravity-fed hot water systems.
- Properties without cold-water storage tanks.
- Utility rooms and installations where stainless-steel construction is preferred.
Frequently Asked Questions
The cylinder has an actual capacity of 150 litres.
The TCEMVD-0150LFD is a direct unvented cylinder using electric immersion heating.
The cylinder has 2 immersion ports, with an immersion specification of 3 kW @ 230 V.
The specified maximum mains water pressure is 10 bar, with an operating pressure of 7 bar.
The cylinder is manufactured from LDX 2101 stainless steel and features a coated mild steel outer casing.
It uses dense PU foam thermal insulation, with a specified heat loss of 1.32 kWh/24h.
The supplied product specification states a 25-year warranty.
Joule Cyclone 150L Direct Standard Unvented Cylinder
The Joule Cyclone TCEMVD-0150LFD combines a 150 litre capacity, direct electric immersion heating, LDX 2101 stainless-steel construction, dense PU foam insulation and mains-pressure hot water performance. With two 3 kW immersion ports, 10 bar maximum mains pressure, 7 bar operating pressure and a 25-year warranty, it is a practical option for compact domestic hot water installations.
