The Joule Cylinder 200L Cyclone Air Direct Standard C is a high-quality direct unvented hot water cylinder designed to provide reliable hot water storage for domestic applications. With a 200-litre capacity and an integrated internal expansion vessel, the Cyclone Air range provides a neat, all-in-one cylinder installation that is popular with both customers and installers.
The cylinder features an internal expansion vessel, similar to the Megaflo-style arrangement, helping create a streamlined installation. A pre-plumbed cold feed assembly is also included to make installation easier, while two 3kW immersion heaters at 230V provide electric heating capability and backup. The unit has a stated safety temperature of 95°C.
200L Capacity
Direct Cylinder
Internal Expansion Vessel
2 Immersions
95°C Safety Temperature
Key Highlights
2 × 3kW
Immersion Heaters
Internal
Expansion Vessel
Applications & Suitability
-
Domestic hot water: Provides 200 litres of stored hot water capacity for domestic applications.
-
Direct hot water systems: Designed as a direct cylinder with electric immersion heating.
-
Streamlined installations: The internal expansion vessel provides a neat, all-in-one cylinder arrangement.
-
Installer-friendly projects: The pre-plumbed cold feed assembly is designed to make installation easier.
-
Higher-capacity requirements: The 200L capacity provides substantial stored hot water capacity.
Key Specifications
| Product |
Joule Cylinder 200L Cyclone Air Direct Standard C |
| Range |
Joule Cyclone Air |
| Expansion Vessel |
Internal (Megaflo-style) |
| Capacity |
200 L |
| Model |
DIRECT |
| Actual Capacity |
200 L |
| Unit Weight Empty |
41 kg |
| Unit Weight Full |
241 kg |
| Number of Immersions |
2 |
| Immersion Specification |
3 kW @ 230V |
| Safety Temperature |
95°C |
Cyclone Air Internal Expansion System
Integrated expansion vessel: The Joule Cyclone Air range incorporates an internal expansion vessel, providing a neat, all-in-one cylinder installation.
Megaflo-style arrangement: The internal expansion vessel follows a similar installation concept to the Megaflo range from Heatrae Sadia, as specified for this product.
Direct Heating & Immersion Backup
The Joule Cyclone Air Direct Standard C is a direct cylinder with an actual capacity of 200 litres. It is equipped with two immersion heaters, each rated at 3 kW @ 230V, providing electric heating capability for the cylinder. The stated safety temperature is 95°C.
200L Storage
Provides 200 litres of stated actual hot water storage capacity.
Two Immersions
Includes two immersion heaters, each specified at 3 kW @ 230V.
Pre-Plumbed Cold Feed
The supplied pre-plumbed cold feed assembly is designed to make installation easier.
Installation & Handling
-
Pre-plumbed cold feed: Included to help simplify the installation process.
-
All-in-one configuration: The internal expansion vessel creates a neat cylinder installation.
-
Empty weight: The cylinder weighs 41 kg when empty.
-
Full weight: The stated full unit weight is 241 kg.
-
Professional installation: Installation should be carried out by a suitably qualified professional in accordance with applicable requirements.
Ideal For
- Domestic properties requiring 200-litre hot water storage
- Direct unvented hot water systems
- Installations benefiting from an internal expansion vessel
- Projects where a neat all-in-one cylinder arrangement is preferred
- Installers looking for a pre-plumbed cold feed assembly
- Applications requiring two electric immersion heaters
Frequently Asked Questions
What is the capacity of the Joule Cyclone Air Direct Standard C?
The cylinder has a stated 200-litre capacity and an actual capacity of 200 litres.
Does this cylinder have an internal expansion vessel?
Yes. The Joule Cyclone Air Direct Standard C features an internal expansion vessel in a Megaflo-style arrangement.
How many immersion heaters does it have?
The cylinder has two immersion heaters, each specified at 3 kW @ 230V.
What is the safety temperature?
The stated safety temperature is 95°C.
What is the weight of the cylinder?
The empty unit weight is 41 kg, while the stated full unit weight is 241 kg.
Is the cold feed assembly pre-plumbed?
Yes. The Joule Cyclone Air range includes a pre-plumbed cold feed assembly designed to make installation easier.
Joule Cylinder 200L Cyclone Air Direct Standard C provides a practical all-in-one hot water storage solution with a 200-litre capacity, internal expansion vessel, pre-plumbed cold feed assembly and two 3kW immersion heaters. Designed as a direct cylinder, it offers a streamlined installation approach for domestic hot water applications.
