Joule Cyclone Platinum 170L Direct Slimline C Unvented Cylinder - TCEMVD-0170SFD
Shipping time: 2–7 days
Please call us for precise delivery dates.
Description
The Joule Cyclone Platinum 170L Direct Slimline C Unvented Cylinder (TCEMVD-0170SFD) is a compact, high-performance direct unvented hot water cylinder designed to deliver mains-pressure hot water where space is limited. Built with a stainless-steel LDX 2101 cylinder and efficient PU insulation, it provides reliable, corrosion-resistant hot water delivery for modern homes and apartments. Ideal for installations that require a slim footprint without compromising capacity, it offers low heat loss and long-term warranty protection.
Key Features
- 170 L actual capacity — generous usable store in a slimline format
- Direct unvented design for mains-pressure hot water to multiple outlets
- Two immersion ports with compatibility for 3 kW, 230 V immersion elements for rapid heating
- LDX 2101 stainless-steel cylinder for corrosion resistance and longevity
- Dense PU foam insulation and coated mild steel outer casing for reduced standby losses
- Low heat loss (1.9 kWh/24h) for improved energy efficiency
- High-pressure capability: max mains 10 bar, operating pressure 7 bar
- Safety temperature rated to 90 °C and tested to BS EN 12897:2016
- 25-year warranty for long-term peace of mind
Ideal Use Cases
- Small to medium-sized homes and apartments needing mains-pressure hot water
- Bathrooms and kitchens requiring reliable high-pressure showers and taps
- Retrofit projects replacing gravity-fed or bulky cylinders with a slimline unvented solution
- Flats and utility spaces where floor or plantroom space is limited
- Installations wanting durable stainless-steel construction and low standby losses
Product Specifications
| Specification | Value |
|---|---|
| Product model | Joule Cyclone Platinum 170L Direct Slimline C Unvented Cylinder (TCEMVD-0170SFD) |
| Brand | CYCLONE |
| ERP Type | DirectUnvented |
| Item Category Code | Stainless |
| Product Group Code | CYCLONE |
| Model Type | DIRECT |
| Actual capacity (Ltr) | 170 |
| Rated capacity (Ltr) | 175 L (listed capacity) |
| Unit weight empty (kg) | 38 |
| Unit weight full (kg) | 208 |
| No immersions | 2 |
| Immersion spec (kW @ 230V) | 3 kW @ 230 V |
| Thermal insulation | Dense PU foam |
| Foam thickness (mm) | 0 |
| Cylinder material | LDX 2101 |
| Outer casing | Coated mild steel |
| Max mains water pressure (Bar) | 10 |
| Operating pressure (Bar) | 7 |
| Safety temp (°C) | 90 |
| Heat loss (kWh/24h) | 1.9 |
| Tested to standard | BS EN 12897:2016 |
| Warranty terms (Year) | 25Y |
