Joule Cyclone Air 200L Indirect Standard Unvented Cylinder TCEMVA-0200LFC
Shipping time: 2–7 days
Please call us for precise delivery dates.
Get Free Delivery on Orders Over £60
For more details, please refer to our Shipping Information.
Description
The Joule Cyclone Air range of cylinders feature an internal expansion vessel (similar to the Megaflo range from Heatrae Sadia). This provides a neat, all-in-one cylinder installation that’s very popular with both customers and installers. The unit is designed for dependable domestic hot water storage, combining efficient insulated construction with indirect heating via an internal coil and electric immersion backup.
This model is an indirect standard unvented hot water cylinder with a 316L stainless steel coil and an LDX 2101 stainless steel cylinder. It has a coated mild steel outer casing for durability. The system includes 1 immersion heater rated at 3kW @ 230V, supporting flexible hot water performance when needed. Key operational performance includes a maximum mains water pressure of 10 bar, an operating temperature of 60°C, an operating pressure of 7 bar, and a safety temperature valve set at 95°C.
| Specification | Value |
|---|---|
| Model name/number | TCEMVA-0200LFC |
| Product Type | Hot Water Cylinder (Indirect Unvented) |
| Range | Joule Cyclone Air |
| Actual Capacity (Ltr) | 188 L |
| Height | 1490 mm |
| Diameter | 540 mm |
| Unit Weight (Empty) | 46 kg |
| Unit Weight (Full) | 243 kg |
| Cylinder Material | LDX 2101 |
| Outer Casing | Coated Mild Steel |
| No Immersions | 1 |
| Immersion Spec | 3kW @ 230V |
| Coil Material | 316L Stainless Steel |
| Foam Thickness | 0 |
| Max Mains Water Pressure (Bar) | 10 bar |
| Operating Temp (C) | 60 °C |
| Operating Pressure (Bar) | 7 bar |
| Safety Temp Valve (C) | 95 °C |
| No Heat Exchangers | 1 |
| Heat Loss | 1.944 |
| Coil 1 Rating (kW) | 21 kW |
| Coil 1 Surface Area (m2) | 0.67 m² |
| Coil 1 Max Prim Pressure (Bar) | 3.5 bar |
| Coil 1 Resistance (Bar) | 0.07 bar |
Important checks before installation
- Compatible with suitable indirect heating systems (coil-based connection).
- Professional installation is required due to pressure and temperature ratings.
