The 22mm × 1" End Feed Bent Cylinder Union connects 22mm copper to a 1" BSP male boss with a swivel union nut, turning through 90° — soldered capillary joint on the copper end, threaded union on the other. The bend takes the pipework straight down or across from the boss without an extra elbow, and the union lets it be disconnected without unsoldering. Manufactured to BS EN 1254 and fits copper tube to BS EN 1057.

Also known as: bent cylinder union, angled cylinder connector, bent union connector, elbow cylinder union, tank union bent.

• Manufactured to BS EN 1254 for capillary (solder) fittings
• Bent cylinder union — 22mm copper × 1" BSP union nut, 90°
• Fits copper tube to BS EN 1057
• WRAS approved
• Solder and flux required — not supplied; fibre washer or PTFE for the union joint
• Sold individually — buy exactly what the job needs
• Suitable for hot and cold water and heating services

End feed means a capillary joint: clean the tube and fitting, apply flux, heat evenly and feed lead-free solder to the mouth of the fitting until a ring forms. See our guide: How to solder end feed fittings.
