McAlpine TSG52-T150SS
The McAlpine TSG52-T150SS is a trapped shower gully with a 50mm water seal and a 2" horizontal outlet, supplied with a 2" swivel outlet fitting to allow the outlet direction to be adjusted on site. For wet rooms and level-access showers. Supplied with a 150mm square polished stainless steel tile, no securing screws.
Specification
| Manufacturer part number | TSG52-T150SS |
|---|---|
| Water seal | 50mm |
| Outlet | 2" horizontal with 2" swivel outlet fitting |
| Socket reducer | 2" x 1 1/2" supplied |
| Cover plate / grating | 150mm square polished stainless steel tile, no securing screws |
| Flow rate | 54 litres per minute |
| Overall depth | 100mm |
| Body material | High quality ABS |
| Standards | BS EN 1253-1:2015 and BS EN 1253-2:2015 |
Features
- Swivel outlet fitting allows the outlet to be rotated to suit the pipe run.
- Top access for cleaning without lifting the gully.
- Removable sediment cup and dip tube assembly.
- Clamp ring secured by four M6 stainless steel screws.
- Suitable for concrete and suspended timber floors.
Trap seal depth is the responsibility of the installer or specifier under Building Regulations. Check the required seal depth before installation.
Do not pour drain cleaner into this product. Do not use acetoxy silicone with this product.
