Joule Invacyl Unvented 250L Direct Cylinder Standard Stainless Steel - TRBMVD-0250LFC
Shipping time: 2–7 days
Please call us for precise delivery dates.
Get Free Delivery on Orders Over £60
For more details, please refer to our Shipping Information.
Description
The Joule Invacyl Unvented 250L Direct Cylinder Standard (TRBMVD-0250LFC) is a high-capacity stainless‑steel hot water cylinder engineered for unvented mains‑pressure systems. Designed for direct electric immersion heating, it supplies generous volumes of ready hot water at mains pressure for larger homes and light commercial sites. With dense PU foam insulation, robust LDX 2101 construction and dual immersion options, it delivers low standby losses, reliable performance and long-term assurance backed by a 25‑year warranty.
Key Features
- Capacity: 250 L actual storage for high hot‑water demand.
- Direct heating: two immersion positions for flexible electric heating or backup.
- Cylinder material: LDX 2101 stainless steel for corrosion resistance and durability.
- Insulation: Dense PU foam with 50 mm foam thickness to minimise heat loss.
- Outer casing: Coated mild steel for added protection.
- Immersion spec: 3 kW @ 230 V per immersion.
- Mains‑pressure operation: maximum mains water pressure 10 bar; operating pressure 7 bar.
- Safety & standards: safety temperature 90 °C; tested to BS EN 50440:2015.
- Warranty: 25‑year warranty for long service life.
Ideal Use Cases
- Large family homes with multiple bathrooms and high hot‑water demand.
- Light commercial properties, offices or small businesses requiring reliable mains‑pressure hot water.
- Installations needing direct electric immersion heating or an electric backup to a primary heat source.
- New‑build or renovation projects where a robust, low‑loss 250 L cylinder is required.
- Plant rooms and utility areas where durable, easy‑maintain storage is preferred.
Product Specifications
| Specification | Value |
|---|---|
| Product model | Joule Invacyl Unvented 250L Direct Cylinder Standard — TRBMVD-0250LFC |
| Actual capacity (Ltr) | 250 |
| Unit weight empty (kg) | 46 |
| Unit weight full (kg) | 296 |
| Cylinder material | LDX 2101 |
| Outer casing | Coated mild steel |
| Thermal insulation | Dense PU foam |
| Foam thickness (mm) | 50 |
| No immersions | 2 |
| Immersion spec (kW @ 230 V) | 3 kW @ 230 V |
| Max mains water pressure (Bar) | 10 |
| Operating pressure (Bar) | 7 |
| Safety temperature (°C) | 90 |
| Tested to standard | BS EN 50440:2015 |
| Warranty terms (Year) | 25Y |
