Description
The Joule Invacyl Unvented 180L Direct Cylinder Standard (TRBMVD-0180LFB) is a robust stainless‑steel hot water cylinder designed for unvented mains‑pressure systems. Providing 180 L of ready hot water, it supports direct electric immersion heating for reliable supply and fast recovery in homes and light‑commercial settings. Dense PU foam insulation, corrosion‑resistant LDX 2101 construction and dual immersion options deliver low standby losses, installation flexibility and long‑term confidence with a 25‑year warranty.
Key Features
- Capacity: 180 L actual storage for consistent hot‑water availability.
- Direct heating: two immersion positions (flexible primary or backup electric heating).
- Durable materials: LDX 2101 stainless‑steel cylinder with coated mild steel outer casing.
- Insulation: Dense PU foam with 50 mm foam thickness to reduce standby heat loss.
- Low standby loss: Heat loss 1.82 kWh/24h.
- Immersion spec: 3 kW @ 230 V per immersion.
- Mains‑pressure ready: Max mains water pressure 10 bar; operating pressure 7 bar.
- Safety & standards: Safety temperature 90 °C; tested to BS EN 50440:2015.
- Manageable weight: Empty 38 kg; full 218 kg for planning handling and installation.
- Warranty: 25‑year manufacturer warranty.
Ideal Use Cases
- Family homes with one or more bathrooms requiring reliable mains‑pressure hot water.
- Light‑commercial properties or small businesses with moderate hot‑water demand.
- Installations needing direct electric immersion heating or electric backup to another heat source.
- New‑builds and renovation projects where a compact, durable 180 L cylinder is required.
- Utility rooms and plant rooms where low heat loss and long service life are priorities.
Product Specifications
| Specification | Value |
|---|---|
| Product model | Joule Invacyl Unvented 180L Direct Cylinder Standard — TRBMVD-0180LFB |
| Actual capacity (Ltr) | 180 |
| Unit weight empty (kg) | 38 |
| Unit weight full (kg) | 218 |
| Cylinder material | LDX 2101 |
| Outer casing | Coated mild steel |
| Thermal insulation | Dense PU foam |
| Foam thickness (mm) | 50 |
| No immersions | 2 |
| Immersion spec (kW @ 230 V) | 3 kW @ 230 V |
| Max mains water pressure (Bar) | 10 |
| Operating pressure (Bar) | 7 |
| Safety temperature (°C) | 90 |
| Tested to standard | BS EN 50440:2015 |
| Heat loss (kWh/24h) | 1.82 |
| Warranty terms (Year) | 25Y |
