Joule Invacyl Standard In-Direct Unvented Cylinder 250 Litre - Stainless Steel
Free Local Shipping
Free Local Shipping on orders over £100. Standard delivery to most UK postcodes within 2-3 working days. Express options available at checkout.
Contact Us
Give Us A Call +44 118 958 8882 Our team is here to help. We will provide expert advice on specifications, compatibility, and delivery
30-day Easy Return
30 days Easy Return — no questions asked. If you're not completely satisfied, send it back within 30 days for a full refund.
Description
The Joule Invacyl Standard In-Direct Unvented Cylinder 250 Litre is a stainless-steel, unvented hot water storage cylinder designed for mains-pressure systems. It stores ~245 L of hot water and heats indirectly via a stainless-steel coil, delivering reliable, high-pressure hot water for domestic or light commercial use. Suited to utility rooms, plant rooms and larger residences, it offers low heat loss and long-term durability backed by an extended warranty.
Key Features
- Actual capacity: 245.3 L for substantial hot-water availability.
- Durable construction: LDX 2101 stainless-steel cylinder with coated mild steel outer casing.
- Indirect heating coil: 316L stainless-steel coil rated 14.97 kW with 0.79 m² surface area.
- High insulation: Dense PU foam for efficient heat retention and low heat loss (1.752 kW/24h).
- Mains-pressure operation: Max mains water pressure 10 bar; operating pressure 7 bar for strong delivery.
- Immersion-ready: 3 kW @ 230 V immersion specification.
- Safety & compliance: Tested to BS EN 12897:2016; safety valve temp 90 °C.
- Low primary resistance: Coil resistance 0.2 bar and max primary pressure 6 bar for efficient flow.
- Warranty: 25-year warranty for long-term reliability.
Ideal Use Cases
- Family homes and larger residences with high hot-water demand.
- Light commercial properties needing reliable mains-pressure hot water.
- Heating systems using boilers, heat pumps or solar thermal as primary heat sources.
- Renovation or new-build projects requiring a robust unvented cylinder.
- Utility or plant rooms where durable, low-loss hot water storage is required.
Product Specifications
| Specification | Value |
|---|---|
| Product model | Joule Invacyl Standard In-Direct Unvented Cylinder 250 Litre |
| Actual capacity (Ltr) | 245.3 |
| Max mains water pressure (Bar) | 10 |
| Operating pressure (Bar) | 7 |
| Operating temperature (°C) | 60 |
| Safety valve temperature (°C) | 90 |
| Unit weight empty (kg) | 51 |
| Unit weight full (kg) | 296 |
| Cylinder material | LDX 2101 |
| Outer casing | Coated mild steel |
| Thermal insulation | Dense PU foam |
| Foam thickness | 0 |
| Heat loss (kW/24h) | 1.752 |
| Coil material | 316L stainless steel |
| Coil 1 rating (kW) | 14.97 |
| Coil 1 surface area (m²) | 0.79 |
| Coil 1 max primary pressure (Bar) | 6 |
| Coil 1 resistance (Bar) | 0.2 |
| Immersion spec | 3 kW @ 230 V |
| No immersions | 1 |
| No heat exchangers | 1 |
| Tested to standard | BS EN 12897:2016 |
| Warranty terms (Year) | 25Y |
