The 491mm diameter makes this cylinder suitable for homes where a standard-width hot water cylinder cannot be accommodated.

Provides 170 litres of nominal hot water storage in a compact slimline cylinder format.

Titanium immersion elements are supplied as standard for durability in hard water installations.

The unvented design operates at 3 bar and includes factory-fitted safety components and an internal floating baffle.

At just 491mm in diameter, the cylinder is designed to fit into spaces where a standard-width cylinder may not be suitable.

Two 3kW titanium immersion elements are fitted as standard, offering a durable heating solution for hard water applications.

The cylinder can deliver a maximum flow rate of 70 l/min at 3 bar according to the supplied specification.

50mm CFC-free polyurethane foam insulation supports the specified standing heat loss of 1.72 kWh/24h.

The integrated floating baffle provides internal expansion capacity without requiring a separate external expansion vessel.

Supplied with factory-fitted T&P valve, 3 bar pressure relief valve, tundish and unvented kit.

The direct unvented configuration uses immersion heating and does not require a pump or header tank.
