EHS Flex 24kW Three Phase Electric Combi Boiler - ALC-3PCO-24F - 24000C Flex
Shipping time: 2–7 days
Please call us for precise delivery dates.
Description
EHS Flex 24kW Three Phase Electric Combi Boiler (24000C Flex) – ALC-3PCO-24F
The EHS Flex 24kW Three Phase Electric Combi Boiler is a compact, modern electric boiler designed to deliver reliable central heating and instant domestic hot water without a flue or gas supply. Built for simple installation and low maintenance, the Flex range is ideal for properties where gas is unavailable or where homeowners want a cleaner, future-ready heating option.
With range-rateable output (12kW to 24kW), the boiler can be set to match the property’s heat loss and hot water needs, helping reduce unnecessary energy use. Quiet operation, a modern control interface, and minimal moving parts make it a practical choice for long-term performance.
Product Application
This model is suited to homes needing a higher-output electric combi solution, providing hot water on demand (no cylinder required) and strong heating performance for radiators and compatible underfloor heating systems (subject to correct design and controls). The no-flue design allows flexible siting in kitchens, utility rooms, loft spaces, or plant rooms.
- Instant hot water (combi) – no hot water cylinder required
- Three-phase supply – suited to higher-output electric installs
- Flexible installation location – no flue required
- Can be paired with suitable controls and renewable strategies (e.g., tariff optimisation and solar PV usage)
Key Features
- Range-rateable heating to match property requirements (12kW–24kW)
- Easy to install and compact wall-mounted design
- Minimal servicing and fewer moving parts for reliability
- Flexible siting – no flue required
- Works with existing radiators (subject to correct sizing and system condition)
- Near-silent operation
- Designed to support low-cost tariff strategies (time scheduling / optimisation with suitable controls)
- 5 year warranty (subject to manufacturer terms & conditions)
Specifications
| Specification | Details |
|---|---|
| Brand | EHS (Electric Heating Systems) |
| Range / Family | Flex |
| Product Code (MPN) | ALC-3PCO-24F |
| Boiler Type | Electric Combi Boiler |
| Model Name | 24000C Flex |
| Heating Output (Range Rated) | 12kW to 24kW |
| Electrical Supply | Three Phase |
| Voltage | 400V |
| Current (Amps) | 36A |
| Recommended Breaker | 40A (TP) |
| Recommended Cable Size | 3 x 6mm² |
| DHW Flow Rate | Up to 12 L/min |
| Max. Heating Pressure | 2.5 bar |
| Min. Heating Pressure | 0.5 bar |
| Max. Flow Temperature | 80°C |
| Min. Flow Temperature | 20°C |
| DHW Connections | 1/2" Male Connector |
| Heating Connection Size | 3/4" Male Connectors |
| PRV Connection Size | 15mm |
| Dimensions (mm) | H630 x W380 x D230 |
| Warranty | 5 Years (Subject to T&Cs) |
Why Choose the EHS Flex 24kW Combi?
If you need a high-output electric combi boiler with flexible installation and simple controls, the EHS Flex 24000C is a strong choice. With no flue requirements, range-rateable output, and on-demand hot water, it’s an excellent electric upgrade for properties moving away from gas.
Available from GetPlumb for fast UK delivery or collection from our Reading branch.
