BSP Pipe and Pipe Thread Sizes: What You Need to Know
BSP (British Standard Pipe) is a widely used thread standard in the UK and around the world for pipes and fittings. BSP threads are available in a range of sizes and are used in a variety of applications, from plumbing and gas installations to industrial and hydraulic systems. In this post, we'll explain the basics of BSP pipe and pipe thread sizes and provide tables to help you convert BSP thread sizes to metric.
BSP Pipe Thread Sizes
|
BSP Size |
Diameter (mm) |
|
1/8" |
9.73 |
|
1/4" |
13.16 |
|
3/8" |
16.66 |
|
1/2" |
20.96 |
|
3/4" |
26.44 |
|
1" |
33.25 |
|
1 1/4" |
41.91 |
|
1 1/2" |
47.80 |
|
2" |
59.61 |
BSP Pipe Thread Pitch
BSP pipe threads have a standard pitch of 14 threads per inch (TPI) for sizes up to 1 inch and 11 TPI for sizes above 1 inch.
BSP Pipe Thread Types
There are two types of BSP pipe threads: parallel and tapered. Parallel threads are used for fittings such as couplings and nipples, while tapered threads are used for joints with a sealant, such as pipe connections to valves and taps
Conclusion
Understanding BSP pipe and thread sizes is essential for anyone working with plumbing and piping systems. By using the tables and charts provided in this article, you can easily convert between BSP and metric measurements and choose the correct pipe and fitting sizes for your project. Whether you are a professional plumber or a DIY enthusiast, having a clear understanding of BSP pipe and thread sizes will make your work more efficient and effective.
